OptimScan 5M 3D High Accuracy Scanner

Available now. Contact us at sales@umax.com for pricing.


OptimScan-5M 3D scanner is the standard 3D scanner released by Shining 3D.

Equipped with 3 mega pixels cameras and latest blue light scanning technology, it has wide application due to its excellent performanc.



Features

Blue Light Scanning Technology

OptimScan-5M Metrology 3D Scanner equipped with Blue Light Technology enables you to scan more kinds of objects with dark color feature or metallic materials.

Adjustable Scan Ranges

Single scan accuracy can reach 0.005mm.
Overall accuracy can be contained within 0.08mm/m.

Higher Performance

5.0 mega pixels cameras bring you higher resolution, better quality.

Faster Scan Speed

Single scan time is under 1.5 seconds.
Data registration is free to switch between automatic alignment and manual alignment.

Suitale for applications of military industry, aerospace industry, molding industry, etc.

Non-contact 3D scanning can be applied in complex component like turbine blade measurement and inspection, taking around 10% of the total time needed with traditional CMM system. Not only faster, but also full dimension inspection and measurement can be carried out.

3D Probe

• Compatible with OptimScan-3M/5M
• Easily measuring the positions that non-contacted scanning is inaccessible, such as very deep holes
• Optical CMM measurement technology
• Wireless bluetooth transmission
• Light and portable design

Reliable and Portable

Projection light is safe for eyes
Small and portable, possible for large size parts scanning
User-friendly cross-bar makes it easier to be carried

 Specifications

Model OptimScan-5M
Single Shot Accuracy 0.005-0.015 mm
Volume Accuracy 0.08 mm/m
Single Scan Speed < 1.5 s
Point Distance 0.04-0.16 mm
Single Scan Range 100x 75 mm /200×150 mm / 400×300 mm
Scan Depth 100-400 mm
Camera Resolution 5.0 MPx2
Light Source Blue light ( LED )
Scan Type Non-contact structure light scanning
Alignment Markers auto-alignment /manual alignment
Output Data Format ASC, STL, PLY, RGE, P3, PF
PC Configuration Requirement CPU: Intel core i7 3770 or better
Display card: NVIDIA GeForce GT 670 or better Memory : 8G DDR3 1600 or be忧er
OS System Support win10 64bit
Operation Temperature 0 - 45 °C

 Applications

 x5-apps-1.jpg       reverse-engineering.png

      3D Inspection                  Reverse Engineering
